3/4" - 240 Bar 261E HYPERCOLD 1001559

Du skal være logget ind for at kunne lave bestillinger

Slangestørrelse: 3/4"
Arbejdstryk (Bar): 240
Bukkeradius (mm): 120

Model/Varenr.: 1001559

Lagerstatus: 51 Stk på lager

Beskrivelse

HYPERCOLD - 261E - 3/4" - 240
1001559
Tube: oil resistant ultra low temperature synthetic rubber.
Reinforcement: two high tensile steel braids.
Cover: smooth up to 1", wrapped over 1". Oil, water, ozone and ultra low temperature resistant synthetic rubber.
Application: hydraulic system with petroleum or water/glycol based fluids, fuel, lubricating oils.
Specially designed for ultra low temperature applications.
Temperature: -55 °C +100 °C (-67 °F +212 °F) air max T = +70 °C (+160 °F)
Length: random
DH SCAN crimp short code: 261E

ID (Dash): 12
ID (mm): 19
ID (in): 3/4"
OD (mm): 27,6
WP (Bar): 240
WP (psi): 3500
BP (Bar): 960
BP (psi): 14000
BR (mm): 120
Weight (kg/m): 0,81

DH SCAN crimp short code: (http://crimp.dunlophiflex.se/Home/Index/DK): 261E
